Product Description
DescriptionThe MOAB Sit-n-Stow Bracket Kit lets you safely stow your MOAB bed panels against the wall of the van and also allows you to use the panels to create bench seating.
Kit includes:
- Two large powder coated wall brackets with installation hardware
- Three small powder coated bench hooks
- Three 3' Adventure Wagon cam-straps
- Two 6' Adventure Wagon hook-cam-straps
- One 8' Adventure Wagon hook-cam-straps
- Four L-track cargo rings
Compatibility
- Designed specifically for the 2007-2019 Mercedes-Benz Sprinter van model 144 & 170 with the Adventure Wagon Modular Interior System
- May be compatible with other interiors but strength, security, and functionality is not guaranteed when installed in a manner other than recommended.
Features
- Store your three MOAB bed panels against one wall of your van using the installed wall brackets, two 6' straps, and one 8' strap.
- Wall brackets can be installed on either driver or passenger side and are permanently mounted i.e. cannot be switched from side to side without tools.
- Panels are secured safely for travel when installed per our instructions.
- Side-wall bench can be created using one MOAB panel, wall brackets, two bench hooks and two 6' straps.
- Remaining panels can be secured to the wall or removed from van. Can also be used as a small bunk.
- Do not drive or carry passengers with panel in the bench configuration! The bench is intended to be set up only when the vehicle is parked and is not safely secured to the vehicle for driving.
- Front bench can be created using one MOAB panel, one wall bracket, three bench hooks and three 3' straps. Once brackets and straps are in place, the front bench panel is removed from the bed rail and lowered into position. The remaining mid and rear panels can stay locked to the bed rails.
- Do not drive or carry passengers with panel in the bench configuration! The bench is intended to be set up only when the vehicle is parked and is not safely secured to the vehicle for driving.
Benefits
- Provide storage for MOAB bed panels:
- without removing from van
- safe for driving
- with access to entire cargo area
- Provides two bench solutions:
- In front of bed platform from side-to-side
- Against either side wall
- Side mount can be used as a small bunk
- Quickly change from one configuration to another in only a few minutes
- Straps provided have many other uses when not deployed for Sit-n-Stow use.
Installation
- Installs in less than 1 hour.
- Wall brackets are permanently mounted to the side wall of your choice. Requires removing one lower panel, drilling two holes, installing two t-nuts, and reinstalling the panel.
- All other components secure to the L-track installed as part of our Modular Interior System.
- Configuring each layout requires a combination of the provided straps and brackets.
- Side-Bench: One long side of the panel rests on the wall brackets. Two 6' straps connect to the wall or ceiling L-track using L-track cargo rings. The other end of each strap connects to a Bench Hook that hooks to the outside frame of the panel.
- Front Bench: Bench can be set up using the forward wall bracket plus one bench hook, 3' strap, and L-track ring on one side and two hook/strap/rings on the other. Once brackets and straps are in place, the front bench panel is removed from the bed rail and lowered into position. The remaining mid and rear panels can stay locked to the bed rails.
- Written installation instructions coming soon.
- Click to see videos:
